Automatic Can Welder QM-400A/B
STWMF’s QM-400A/B fully automatic can welder is our independently developed economical machine. Featuring digital control, it’s simple to operate with a maximum production capacity of 400 cans/minute.
Main features- Wide application range for different can types. Tin plate thickness of 0.16 to 0.3mm, maximum wire welding speed of 65m/minute, ensuring a highly efficient production.
- Digital control system. The full servo control for copper wire driving system precisely controls the welding speed.
| Type | QM-400A | QM-400B |
| Welding speed | 15-55m/min | 15-65m/min |
| Production capacity | 400 cans/min(max.) | |
| Welding points distance | 0.5-0.9mm | |
| Overlap | 0.4mm | |
| Sheet thickness | 0.16-0.3mm | |
| Can diameter | Φ52-Φ110mm | |
| Can height | 60-265mm | |
| Materials | Tinplate, Ni plate | |
| Tin coating | Tin: #5-#100 | |
| Temper | T2.5-DR8 | |
| Copper wire | Φ1.38mm, Φ1.5mm | |
| Power | Three phase, Voltage: 380V, Frequency: 50Hz, Electric consumption: 60kVA | |
| Welding frequency | 100-900Hz | |
| Cooling water | 392-490kPa,12-18℃, 20L/min | |
| Compressed air | 490kPa, 800L/min | |
| Dimensions | 2850×2100×2050mm | |
